In this section we introduce the logic (un)SecureNDsim, a natural deduction calculus whose rules define how agents can execute access operations on (atomic) formulas and their negations. The proof-theoretic setting of the language has several advantages. First, it allows us to clearly express the algorithmic protocol introduced in “Design and implementation” section through pairs of rules that fully describe the semantics of each operation available to agents. Second, it provides the means to explore meta-theoretical properties of the model which the simulation cannot offer. Finally, it lays down preparatory work for the possible formal verification of the protocol.
Agents of the language are epistemically characterised and their different access privileges on contents are reflected in an order relation. We distinguish two types of agents who behave differently in the context of information transmission:
-
sceptic agents: they pay an epistemic cost by performing a checking operation before trusting received information;
-
lazy agent: they distrust the information when this is not consistent with their current knowledge.
Obviously, this distinction does not cover the whole spectrum of possible epistemic attitudes towards information received and it could be offered in a graded scale. We limit ourselves here to these two basic cases. While the logic is rigid with respect to how these attitudes are executed, in the simulation model developed in “Design and implementation” section, we allow for slight changes of behaviour, i.e. where we establish that only a certain fraction of sceptic agents check information.
Agents’ operations are those typical of access control models, namely reading and writing, where the former is here understood as message receiving, and the latter as message passing. They are further enhanced formally by the following operations:
-
verification: it is required either by a top-down reading operation, i.e., when message passing is executed from below in the hierarchy; or by a reading operation performed by a sceptic agent;
-
falsification: it is formulated as closure of verification under negation and it follows from reading contents that are inconsistent with the current knowledge of the receiver; or from a reading operation performed by a lazy agent;
-
trust: is a function that follows from verification, when the content passed is consistent with the knowledge of the receiver;
-
distrust: it is formulated as closure of trust under negation and it follows from falsification.
It is important to stress that, according to this operational semantics, agents do verify or falsify information on the basis of a contextual evaluation. Agents are here presented in a contextually empty process of information transmission and their evaluation is purely based on the evaluation of trustfulness and distrustfulness on the basis of criteria of majority and origin. In this sense, our logic, the algorithm and the simulation focus on the role of trust and distrust as independent from truthfulness criteria, while consistency requirements are crucial. In other words, we do not establish beforehand which of two contradictory atoms of information is true.
In line with a proof-theoretical approach, we define rules that allow to introduce a given function from premises, and one to eliminate it, i.e., to obtain a conclusion without such function. Such a pair of rules defines syntactically the meaning of access operations, including verification, trust and their negations. (un)SecureNDsim is here introduced as a stand-alone formal system, but it can be seen as a para-complete fragment of the logic SecureND presented in (Primiero and Raimondi 2014). This logic has been specifically designed to resolve situations of unintended (and therefore possibly risky) trust transitivity of the form:
Alice trusts Bob and Bob trusts Carol; therefore Alice trusts Carol.
In (Boender et al. 2015b), the logic is formally verified through translation to a Coq protocol and applied to a problem of trust transitivity in software management. In (Primiero 2016), the calculus is further extended with negation to define the logic (un)SecureND, which includes two negative trust protocols: one for misplacement of trust (mistrust), on for betrayal (distrust). (un)SecureNDsim models the latter in the context of message passing in a network of ordered agents with contradictory information. The extension to a verification protocol is a new property added to this family of logics by the present fragment.
We first introduce the syntax of the system and the main properties of the underlying access control model. We further illustrate in some details the rules and some minimal meta-theoretical properties of the related derivability relation. Finally we illustrate some structural properties of (un)SecureNDsim derivations concerning especially validity and the role of trust instances in the length of such derivations. These formal properties are later experimentally tested in “Experimental results” section.
Formal preliminaries
Definition 1
The syntax of (un)SecureNDsim is defined by the following alphabet:
$$\begin{array}{l} V^{<}:= \{\mathtt{lazy(v_{i})}, \mathtt{sceptic(v_{i})}\}\\ \phi^{V}:= p^{v_{i}} \mid \neg \phi^{V} \mid Read\left(\phi^{V}\right)\mid Verify\left(\phi^{V}\right) \mid Write\left(\phi^{V}\right)\mid Trust\left(\phi^{V}\right)\\ \Gamma^{V}:=\{\phi^{v_{i}}_{1}, \dots, \phi^{v_{i}}_{n}\}; \end{array} $$
V
< indicates the set of lazy and sceptic agents, each denoted by \(\phantom {\dot {i}\!}v_{i},{v{j}},\dots \). The apex works as a formal reminder that agents are ordered according to an order relation <. The order relation < over V×V models the dominance relation between agents: v
i
<v
j
means that agent v
i
has higher relevance (e.g., in terms of security privileges) than agent v
j
. ϕ
V is a meta-variable for boolean atomic formulae closed under negation and functions for reading, writing, verification and trust. It should be stressed that the current formal model and the subsequent algorithmic model refer to atomic information for simplicity, but the complexity of the formula representing the transmitted information is entirely irrelevant for our results. We use \(\phantom {\dot {i}\!}\Gamma ^{v_{i}}\) to express a set of formulae typed by one agent v
i
∈V, typically the sender, in which a given formula ϕ
V is derivable. \(\phantom {\dot {i}\!}\Gamma ^{v_{i}}\) is called the context in which \(\phantom {\dot {i}\!}\phi ^{v_{i}}\) is derived. We denote an empty context by ·⊩.
Definition 2
(Judgement) A judgement \(\Gamma ^{v_{i}} \vdash \phi ^{v_{j}}\) states that a formula ϕ is valid for agent v
j
in the context Γ of formulas (including operations) of agent v
i
.
Our judgements express thus some operation that the agent on the left-hand side of the derivability sign performs on information typed the agent on the right-hand side of the same sign. When message passing includes more than one agent, this is encoded in the system by an extension of the context, denoted as \(\phantom {\dot {i}\!}\Gamma ^{v_{i}};\Gamma ^{v_{j}}\). A judgement stating the validity of a formula for one agent under a (possibly extended) context of formulas of (an)other agent(s) matches the procedure Transmission introduced below in “Design and implementation” section to extend a given graph G with a newly labelled vertex.
Assuming v
i
<v
j
, valid privilege transfers for access control in our system are summarised as follows by judgements of (un)SecureNDsim:
-
\(\Gamma ^{v_{j}}\vdash Read(\phi ^{v_{i}})\): reading is always allowed when messages come from up in the order relation; this is not always the case in access control models, where one might establish reading privileges to hold only upwards, e.g. in the case where strict security is applied; we model a less strict scenario, where agents can always read information that is passed top-down.
-
If \(\Gamma ^{v_{i}}\vdash Read(\phi ^{v_{j}})\) then \(\Gamma ^{v_{i}}\vdash Verify(\phi ^{v_{j}})\): messages coming upwards from below in the order relation are passed on under a verification function.
-
If sceptic(
v
j
), and \(\Gamma ^{v_{j}}\vdash Read(\phi ^{v_{i}})\), then \(\Gamma ^{v_{j}}\vdash Verify(\phi ^{v_{i}})\): we further wish to enhance the structure of the model by requiring that the message passing is qualified by verification in one additional case: not only because the transmission is executed upwards in the dominance relation, but also because a sceptic agent is on the receiving side and it verifies the information.
-
If lazy(
v
j
), and \(\Gamma ^{v_{j}}\vdash Read(\phi ^{v_{i}})\), then \(\Gamma ^{v_{j}}\vdash \neg Verify(\phi ^{v_{i}})\): when a lazy agent is on the receiving side, information is not verified.
-
If \(\Gamma ^{v_{i}}\vdash Read(\phi ^{v_{j}})\) and \(\Gamma ^{v_{i}}\vdash \neg \phi \), then \(\Gamma ^{v_{i}}\vdash \neg Verify(\phi ^{v_{j}})\): when a content read from below contradicts current knowledge, refutation is modelled as negation of verification.
Notice that in the last two cases refuted verification leads to negated trust. The rule system (un)SecureNDsim modelling these cases is introduced in Fig. 1 and it assumes that v
i
<v
j
holds. The first rules are for inductive construction of a context \(\phantom {\dot {i}\!}\Gamma ^{v_{i}}\). Any such context, also called user profile, is required to be consistent (i.e., it admits only one of ϕ and ¬ϕ) after a message passing operation is concluded. We use a standard context-extension syntax \(\phantom {\dot {i}\!}\Gamma ^{v_{i}}; \phi ^{v_{j}}\) to indicate that the extension of the profile for agent v
i
with a formula ϕ from agent v
j
preserves consistency. Extensions that do not preserve consistency are not allowed. The rule read_down establishes that if a message is owned by a user v
i
it can be read downwards (this is the first of the above privilege transfers). The rule read_elim is the corresponding elimination rule: a message that is read (first premise) and preserves consistency (second premise) can be owned, expressed by the change of label in the formula ϕ. We now consider the case of access from upwards in the dominance relation. The rule verify_high says that if a message owned by an agent v
j
is read from another agent v
i
higher in the dominance relation, then a verification action is required. Similarly, by rule verify_sceptic a verification procedure is called when the receiver is sceptic (independently from the order, hence also when the receiver is below). The rule trust is the elimination rule for the verification procedure: if verify is called and the message preserves consistency (i.e., is derivable in the current agent’s profile), then the link between the agents about that message is trusted. Trust elimination corresponds to message passing according to write_trust. The current simple setting of (un)SecureNDsim models information rejection through a consistency checking rule: every message passing operation is eventually accepted if consistent. Verification, and accordingly Trust, are not implemented in two cases: by rule unverified_contra when messages received conflict with currently held contents; and by rule unverified_lazy when when a lazy agent is on the receiving side. Resolution of two received contents inconsistent with one another are resolved below through an additional definition based on popularity (see Definition 5). Missing verification implies distrust, and this in turn passing the opposite message by distrust_elim.
Example 1
A simple derivation of message passing (assuming v
i
<v
j
):
This derivation illustrates a message ϕ written by agent v
j
, read by agent v
i
, verified and written to be passed further on. This standard case holds also if v
i
∈sceptic_node (even assuming v
j
<v
i
); if v
i
∈lazy_node, then the verification passage is skipped to infer write directly.
Proposition 1
Any successful (un)SecureNDsim message-passing operation is a derivation tree including a Write-Read-(Verify-Trust)-Write series of sequents.
Standard logical notions can be formulated as follows:
Definition 3
(Satisfiability) An (un)SecureNDsim judgement \(\Gamma ^{v_{i}}\vdash \phi ^{v_{i}}\) is satisfied if there is a derivation D and a branch D
′⊆D with a final step terminating with such a judgement.
Definition 4
(Validity) An (un)SecureNDsim judgement Γ
V⊩ϕ
V is valid if there is a derivation D and for all branches D
′⊆D and for all agents v
i
∈V, there is a final step terminating with such a judgement.
Structural properties on derivations
By Proposition 1, verification and trust are optional steps in a derivation if the message is received by a lazy agent. This suggests that each derivation (or branch thereof) can be analysed in view of its length to count the number of trust rule instances occurring in it.1 This allows us to identify the number of times an atomic message ϕ has been trusted in a given derivation D. We denote such measure by \(\phantom {\dot {i}\!}\mid \!{Trust}(\phi ^{V})\!\mid _{D}\).
Theorem 1
∣ Trust(ϕ
V) ∣
D
=∣ Verify(ϕ
V) ∣
D
, for all v
i
∈V.
Proof
By induction on the length of D, provided that verify_high and verify_sceptic are the only rules that introduce a formula \(\phantom {\dot {i}\!}Verify(\phi ^{v_{i}})\) which is the premise of a trust rule. □
This computable method allows us to offer a simple resolution for the case in which consistency fails and one wants to decide on the basis of the more trusted formula on the derivation tree.
Definition 5
(Conflict Resolution by Trust Majority) Given a derivation D
1 terminating in \(\Gamma ^{v_{i}}\vdash Write(\phi ^{v_{i}})\) and a derivation D
2 terminating in \(\Gamma ^{v_{j}}\vdash Write(\neg \phi ^{v_{j}})\), a new step holds which takes as premises \(\Gamma ^{k}\vdash Read(\phi ^{v_{i}})\) and \(\Gamma ^{k}\vdash Read(\neg \phi ^{v_{j}})\) respectively, and concludes \(\Gamma ^{v_{k}} \vdash \phi ^{v_{k}}\) if and only if \(\mid \!Trust(\phi ^{V})\!\mid _{D_{1}} > \mid \!Trust(\neg \phi ^{V})\!\mid _{D_{2}}\).
This suggests that at any stage of branch merging, the most popular (trusted) content is preserved, hence enforcing a network effect.
A different resolution strategy can be enforced by computing the number of times an atomic message ϕ has been distrusted in a given derivation D. We denote such measure by ∣ DisTrust(ϕ
V) ∣
D
.
Theorem 2
∣ DisTrust(ϕ
V) ∣
D
=∣ ¬Verify(ϕ
V) ∣
D
, for all v
i
∈V.
Proof
By induction on the length of D, provided that unverified_contra and unverified_lazy are the only rules that introduce a formula \(\phantom {\dot {i}\!}\neg Verify(\phi ^{v_{i}})\) which is the premise of a distrust rule. □
Definition 6
(Conflict Resolution by Distrust Majority) Given a derivation D
1 terminating in \(\Gamma ^{v_{i}}\vdash Write(\phi ^{v_{i}})\) and a derivation D
2 terminating in \(\Gamma ^{v_{j}}\vdash Write(\neg \phi ^{v_{j}})\), a new step holds which takes as premises \(\Gamma ^{k}\vdash Read(\phi ^{v_{i}})\) and \(\Gamma ^{k}\vdash Read(\neg \phi ^{v_{j}})\) respectively, and concludes \(\Gamma ^{v_{k}} \vdash \phi ^{v_{k}}\) if and only if \(\mid \! DisTrust(\phi ^{V})\!\mid _{D_{1}} < \mid \! DisTrust(\neg \phi ^{V})\!\mid _{D_{2}}\).
From Definition 4, the following holds:
Lemma 1
For each (un)SecureNDsim derivation D with a valid formula Γ
V⊩ϕ
V, there is a graph G that is unanimously labelled by ϕ.
Proof
The proof requires to construct a graph G with a node for each distinct v
i
∈V occurring in D and an edge for each judgement instantiating one or more rules with two distinct nodes on each side of the derivability sign. Starting from the node occurring at the highest position of D validating ϕ, by application of one or more sequences of rules the conclusion in such branch of D represents a new node in G labelled by ϕ. If all branches of D terminate with a formula validating ϕ, as by assumption and according to Definition 4, then all nodes in G will be labelled by ϕ. □
The construction of such a graph G for experimental purposes is the aim of “Related work” section. Notice, moreover, the following structural properties on SecureND
sim derivations.
Lemma 2
For a derivation D of (un)SecureNDsim, the value of ∣ Trust(ϕ
V) ∣
D
is directly proportional to the number of verify_high rule applications and the number of distinct sceptic(
v
i
)∈V occurring as labels in the premises of the derivation.
Proof
By structural induction on D, selecting the appropriate step as indicated by Theorem 1. □
Lemma 3
For a derivation D of (un)SecureNDsim, the value of ∣ ¬Trust(ϕ
V) ∣
D
is directly proportional to the number of unverified_contra rule applications and the number of distinct lazy(
v
i
)∈V occurring as labels in the premises of the derivation.
Proof
By structural induction on D, selecting the appropriate step as indicated by Theorem 2. □
Lemma 4
Given a (un)SecureNDsim derivation D, the formula \(\Gamma ^{v_{i}}\vdash \phi ^{v_{i}}\) converges to validity in D and to full labelling in the corresponding graph G as a direct function of:
-
the number of instances of the verify_high rule applications.
-
the number of instances of the verify_sceptic rule applications, for each v
i
∈V.
where \(\phantom {\dot {i}\!}\phi ^{v_{i}}\) occurs in the conclusion, and as an inverse function of:
-
the number of instances of the unverified_contra rule applications.
-
the number of instances of the unverified_lazy rule applications, for each v
i
∈V.
where \(\phantom {\dot {i}\!}\phi ^{v_{i}}\) occurs in the first premise.
Proof
This follows directly by Lemmas 2 and 3, and for the graph analysis by Lemma 1; the more verification operations and the more sceptic agents, the higher the convergence towards validity; the more distrust operations on the same formula, and the more the lazy agents, the lower the convergence. □
We offer in the following sections an agent based simulation which implements the set of rules described in (un)SecureNDsim and proceed with an experimental analysis of its conditions and results.
